WS 160S
Product Features:
1. Advanced inverter technology enables high working frequency. Small, light and portable.
2. HF supercharged arc-start and hot pulse arc-start. Abundant welding current, high price-performance ratio.
3. Protection against over-voltage and over-current.
4. Output features specially designed for wire-feeding welding, nice form of welded seam.
5. Designed for a wide range of input voltages. High duty cycle, suitable for continuous operations.
6. Simple and clear structure, easy maintenance. Reliable and endurable.
Main Parameters Table:
| Input voltage (V)： | 220V | Power factor： | 0.73 | Rated input current (A)： | 16 |
| No-load loss (W)： | 35 | Output current (A)： | 10-160 | Housing Protection grade： | IP21 |
| Rated output volt.(V)： | 16.4 | Rated output current (A)： | 160 | Insulation grade： | F |
| Max welding thickness (mm)： | 6 | Duty cycle (%)： | 60 | Efficiency (%)： | 85 |
| Weight (kg)： | 8 | Dimensions (mm)： | 371×155×287 | ||
| Remarks： | Input voltage frequency should be 50Hz | ||||
| No-Load voltage(v) | 40 | ||||
