Máy Cắt Plasma Cut 120
Features
Easy to cut thick metal plate in a fast and economical way.
Suitable for cutting stainless steel, copper, carbon steel and aluminium, etc.
Easy to operate, smooth cutting performance.
HF non-touch arc-starting cutting.
Parameters:
| Item | CUT120 |
| Input power voltage/frequency（V） | AC400V±10% / 50/60 |
| Rate input power capacity（KVA） | 20 |
| No-load voltage（V） | 270 |
| Current range（A） | 20-110 |
| Rated output voltage（V） | 124 |
| Duty cycle（%）(25℃） | 60 |
| Efficiency | 85 |
| Power factor cos? | 0.93 |
| Insulation class | F |
| Protection class | IP23 |
| Arc-starting | Non-touch |
| No-load loss | 100 |
| Weight（kg） | 35 |
| Dimensions （mm） ( L×W×H ) |
475×330×370 |
| Gas flow(m3/min) | 0.5 |
| Max.Cutting thickness(mm) | 35 |
