TIG 160SII
Features
TIG160SII,ABS plastic case,water splash resistant,anti-static,anti-corrosive.
Small size,light weight,high quality construction and power saving.
High frequency DC TIG ignition.
Smooth arc and stable welding performance.
Automatic over-voltage and over-current protection.
Quick connect torch and gas fittings.
Auto compensation for voltage fluctuation.
The size and weight of these machines makes them portable and therefore ideal for site applications.
High strength case construction for industrial applications.
Parameters:
| Type | TIG160S |
| Input volt（V） | Single phase AC230V±15% |
| Frequency (Hz) | 50/60 |
| Input current（A） | 21 |
| No-load volt（V） | 42 |
| Output current range | 10～200A |
| Rated volt（V） | 18V |
| Post-flow Time（S） | 2.5，5 |
| Valley-down current | —- |
| Duty cycle | 60% |
| No-load loss（W） | 35 |
| Arc-starting | HF |
| Efficiency | 85% |
| Power factor | 0.93 |
| Insulation class | B |
| Protection class | IP23 |
| Weight （kg） | 8 |
| Dimensions(mm) | 371×155×295/376×172×304 |
